Solid Copper Rods
- Manufactured from solid C11000 copper.
- Excellent longevity in most soils.
- Listed to UL-467 specification.
- Made in USA.
Veteran owned company.
| Catalog Number | Diameter X Length | Diameter x Length (metric) Approximate | Actual Diameter Inches | Rod Listing | Sub & MasterBundle | Wt. per 100 lb (kg) | NAED UPC No. 632591- |
|---|---|---|---|---|---|---|---|
C5008 | 1/2" x 8' | 12.8 mm x 2.4 m | 0.500 - 0.515 | UL | 5/25 | – | 61517-4 |
| C5010 | 1/2" x 10' | 12.8 mm x 3 m | 0.500 - 0.515 | UL | 5/25 | – | 61518-1 |
| C6258 | 5/8" x 8' | 15.9 mm x 2.4 m | 0.623-0.627 | UL | 5/25 | 950 (431) | 61488-7 |
| C6260 | 5/8" x 10' | 15.9 mm x 3 m | 0.623-0.627 | UL | 5/25 | 1190 (540) | 61489-4 |
| C7508 | 3/4" x 8' | 19.05mm x 2.4 m | 0.748-0.752 | UL | 5/25 | 1370 (621) | 61519-8 |
| C7510 | 3/4" x 10' | 19.05 mm x 3 m | 0.748-0.752 | UL | 5/25 | 1710 (776) | 61490-0 |
| C1008 | 1" x 8' | 25.4 mm x 2.4 m | 0.998-1.002 | UL | 5/25 | 2440 (1107) | 61520-4 |
| C1010 | 1" x 10' | 25.4 mm x 3 m | 0.998-1.002 | UL | 5/25 | 3040 (1379) | 61521-1 |
